Place of Origin:
Hunan, China
Brand Name:
ZOOMLION
Model Number:
47X-5RZ
Contact Us
Main Parameters
| Model | ZLJ5339THB 47X-5RZ | ||
| Pumping system | Max. Theor. output | m3/h | 170/120 |
| Max. Theor. concrete output Pressure | MPa | 8.3/12 | |
| Rated working pressure | MPa | 35 | |
| Pumping frequency | min-1 | 25/18.5 | |
| Hopper capacity | L | 600 | |
| Filling height | 1540 | ||
| Hydraulic system type | Open loop | ||
| Distribution valve | S valve | ||
| Oil cylinder dia.×stroke | mm | Φ150×2100 | |
| Concrete cylinder dia.×stroke | mm | Φ260×2100 | |
| Hydraulic oil cooling | Air cooling | ||
| Recommended concrete slump | cm | 12~23 | |
| Max. aggregate dimension | mm | 40 | |
| Placing boom | Structure type | 47X-5RZ | |
| Placing depth | m | 47 | |
| Horizontal distance | m | 42.7 | |
| Placing depth | m | 33.4 | |
| Slewing angle | ±270° | ||
| Boom number | 5 | ||
| The length of boom section | mm | 9380/8130/7930/8610/8950 | |
| Sections folding angle | 90°/180°/180°/240°/180° | ||
| Pipe diameter | mm | 125 | |
| End hose length | mm | 3000 | |
| Min. height of opening placing boom | mm | 9700 | |
| Outriggers span (front×rear×side) | mm | 9310×9675×9420 | |
| Chassis and the whole machine | Chassis model | ACTROS 3341 6×4 | |
| Wheelbase | mm | 4500+1350 | |
| Engine type | OM501LA | ||
| Engine power | kW/(r/min) | 300/1800 | |
| Engine moment | N.m/(r/min) | 2000/1080 | |
| Maximum displacement | cc | 11946 | |
| Oil tank cubage | L | 400 | |
| Tail gas exhaust standard | 欧Ⅳ | ||
| Total weight | kg | 34000 | |
| Overall dimensions | mm | 12020×2500×4000 | |
| Others | Lubrication mode | Automatic lubrication | |
| Oil tank volume | L | 780 | |
| Control mode | Manual+remote control | ||
| Maximum water pressure | MPa | 7 | |
| Water tank volume | L | 400 | |
| Pipe cleaning mode | Water cleaning/dry cleaning | ||
